FAG Axial angular contact ball bearings 234720-M-SP

ByFAG
Price on request

Axial angular contact ball bearings 234720-M-SP, double direction, separable, restricted tolerances
Radial loadAxial load in one directionAxial load in two directionsNot sealedGrease lubricationOil lubrication
Axial angular contact ball bearings 234720-M-SP, double direction, separable, restricted tolerances
d 103 mm
D 150 mm
B 60 mm
B1 15 mm
C 30 mm
Da H12 140,5 mm
d1 133 mm
da h12 120,5 mm
ds 4,8 mm
ns 9,5 mm
r1 min 0,3 mm
ra max 1,5 mm
ra1 max 0,3 mm
rmin 1,5 mm
m 2,54 kg
Mass
Ca 67000 N
Basic dynamic load rating, axial
C0a 226000 N
Basic static load rating, axial
nG Fett 3800 1/min
Limiting speed for grease lubrication
nG Öl 5000 1/min
Limiting speed for minimal quantity oil lubrication
Cua 18100 N
Fatigue limit load, axial

FAG pricelist published on july,2017

Need Help? Call us on : +91 - 9222 666 999

FAG Axial angular contact ball bearings 234720-M-SP

By FAG

Axial angular contact ball bearings 234720-M-SP, double direction, separable, restricted tolerances
Radial loadAxial load in one directionAxial load in two directionsNot sealedGrease lubricationOil lubrication
Axial angular contact ball bearings 234720-M-SP, double direction, separable, restricted tolerances
d 103 mm
D 150 mm
B 60 mm
B1 15 mm
C 30 mm
Da H12 140,5 mm
d1 133 mm
da h12 120,5 mm
ds 4,8 mm
ns 9,5 mm
r1 min 0,3 mm
ra max 1,5 mm
ra1 max 0,3 mm
rmin 1,5 mm
m 2,54 kg
Mass
Ca 67000 N
Basic dynamic load rating, axial
C0a 226000 N
Basic static load rating, axial
nG Fett 3800 1/min
Limiting speed for grease lubrication
nG Öl 5000 1/min
Limiting speed for minimal quantity oil lubrication
Cua 18100 N
Fatigue limit load, axial

FAG pricelist published on july,2014

Need Help? Call us on : +91 - 9222 666 999

Technical Details

Model No 234720-M-SP
