SKF Deep groove ball bearings single row 6303-2Z

BySKF
Price on request

Deep groove ball bearings 6303-2Z, main dimensions to DIN 625-1, gap seals on both sides
Radial loadAxial load in one directionAxial load in two directionsSealed on both sidesLifetime lubrication, freedom from maintenanceGrease lubrication
Deep groove ball bearings 6303-2Z, main dimensions to DIN 625-1, gap seals on both sides
d 17 mm
D 47 mm
B 14 mm
D2 39,3 mm
Da max 41,4 mm
d1 26,2 mm
da min 22,6 mm
ra max 1 mm
rmin 1 mm
m 0,117 kg
Mass
Cr 14400 N
Basic dynamic load rating, radial
C0r 6500 N
Basic static load rating, radial
nG 18900 1/min
Limiting speed
nB 15900 1/min
Reference speed
Cur 425 N
Fatigue limit load, radial

SKF pricelist published on july,2017

Need Help? Call us on : +91 - 9222 666 999

SKF Deep groove ball bearings single row 6303-2Z

By SKF

Deep groove ball bearings 6303-2Z, main dimensions to DIN 625-1, gap seals on both sides
Radial loadAxial load in one directionAxial load in two directionsSealed on both sidesLifetime lubrication, freedom from maintenanceGrease lubrication
Deep groove ball bearings 6303-2Z, main dimensions to DIN 625-1, gap seals on both sides
d 17 mm
D 47 mm
B 14 mm
D2 39,3 mm
Da max 41,4 mm
d1 26,2 mm
da min 22,6 mm
ra max 1 mm
rmin 1 mm
m 0,117 kg
Mass
Cr 14400 N
Basic dynamic load rating, radial
C0r 6500 N
Basic static load rating, radial
nG 18900 1/min
Limiting speed
nB 15900 1/min
Reference speed
Cur 425 N
Fatigue limit load, radial

SKF pricelist published on july,2014

Need Help? Call us on : +91 - 9222 666 999

Technical Details

Model No 6303-2Z
Price on request
